Artec Leo Review

Artec Leo is the smartest 3D scanner at the moment.

The best choice for fast, accurate and convenient scanning in any conditions and any objects, during which you observe the creation of a 3D model of the object directly on the built-in touch HD display:

• There is no need to apply markers, it is easy to start working with Artec Leo, just like with a regular video camera: point at the object and start shooting;
• Wide possibilities of synchronization with additional devices;
• Professional lens with a large diameter;
• Built-in 9-axis inertial system.

A powerful built-in processor and battery, together with a built-in SSD drive and the possibility of wireless connection of the Artec Leo portable scanner, make this model a really convenient professional 3D scanner of the new generation, created for the comfort of the user.

The Leo 3D scanner is a really convenient professional 3D scanner of the new generation. As seen in Artec Leo review, it is designed for the convenience of the user in the process of scanning almost any object and in any conditions, during which you observe the creation of a 3D model of the object directly on the built-in touch HD display.

Scanning with Artec Leo is as simple as video recording

Built-in automatic data post-processing technology: you can watch the creation of a 3D model in real time right on the scanner screen.

• Rotate the resulting 3D model, check whether all areas are captured, and scan the missed areas;
• 3D reconstruction speed up to 80 frames per second, thanks to which Artec Leo is the fastest portable 3D scanner today;
• Wide image capture angle for fast and accurate scanning of large areas. Zoom scanning for accurate capture of small details.


Artec Leo is equipped with a powerful built-in processor and a built-in battery, a touch screen and the ability to connect wirelessly. All this ensures absolute freedom of movement during scanning. The absence of the need to connect Artec Leo to a computer and power supply makes it free from wires and auxiliary equipment. Now you can scan simply by holding the scanner on your outstretched arm.

1. Feel the complete independence of Artec Leo in the scanning process, connect an additional screen via Wi-Fi and download data with one push of a button;
2. Excellent rendering of texture and shape. A unique optical system developed in Artec 3D, which combines a 3D camera and a color camera in one lens, providing the most perfect process of reading data on texture and surface geometry;
3. Artec Leo review proves that it’s really improved color rendering. Artec Leo uses vertical emitting laser (VCSEL) illumination technology, innovative in the field of 3D. This gives the scanner an unsurpassed ability to pick up hard-to-read texture such as human skin, and it scans beautifully in extremely bright light conditions;
4. The technology also allows you to adjust the intensity of the backlight for even better color rendering;
5. Scanning without markers. As with other Artec 3D scanners, the Leo scanner reliably tracks a surface based on a combination of geometry and texture, so there is no need to apply and then remove markers. Just point the scanner at the object and start shooting;
6. Using advanced technologies, including the NVIDIA® Jetson ™ platform, which is the scanner’s own embedded computer, equipped with a Quad-core ARM® Cortex®-A57 MPCore CPU and NVIDIA Maxwell ™ 1 TFLOPS GPU with 256 NVIDIA® CUDA® Cores;
7. A built-in 9-axis inertial system combining an accelerometer, gyroscope and compass provides the scanner with information about the location environment and position in space. Also, the scanner is equipped with a “two-in-one” optical system, created specifically for accurate recognition of both texture and surface geometry;
8. Built-in SSD. You can store up to 256 GB on the built-in SSD. You can also expand the storage capabilities by writing data to a micro SD memory card;
9. 3D images with extended dynamic range (or 3D HDR) for objects with difficult-to-scan details;
10. Artec Leo has the ability to synchronize with additional devices. It can be connected to a manipulator or conveyor system for automatic scanning. Leo can be synced with multiple devices to be used in other 3D scanning setups;
11. Carefully thought out ergonomic design, thanks to which it is easy and convenient to scan with one hand.

Where to use

The Leo 3D scanner from Artec is able to capture large areas and the smallest surface details equally well. This makes it possible to use it to scan a wide variety of objects: from small spare parts to the human body, cars, boats or crime scenes. As with other Artec 3D scanners, its range of applications is vast, including industrial production and quality control, healthcare, forensics, advertising and online commerce. This 3D scanner has a built-in wireless adapter and processor, thanks to which various devices can be connected to Artec Leo, which significantly expands your capabilities in any field of activity.

Specifications:

Scanner type Portable

3D accuracy, up to 0.1 mm

3D resolution, up to 0.5 mm

Accuracy depending on the distance, up to 0.03% per 100 cm

Working distance 0.35 – 1.2 m

The catchment area has a volume of 160,000 cm³

Linear field of view at close range, H × W 244 × 142 mm

Linear field of view at a long distance, H × W 838 × 488 mm

Angular field of view, H × W 38.5 × 23°

Texture reading E

The resolution of the texture is 2.3 MP

Color transfer 24 bpp

Speed ​​of 3D reconstruction for real-time gluing, up to 22 frames/sec

Speed ​​of 3D reconstruction for 3D video, up to 44 frames/sec

Speed ​​of 3D reconstruction in 3D video stream mode, up to 80 frames/sec

Data collection speed, up to 3 million points/sec

3D exposure time 0.0002 sec

2D exposure time 0.0002 sec

VCSEL 3D illumination

2D illumination White 12-LED matrix

Position sensors Built-in 9-axis inertial system

Touch screen Built-in touch screen 5.5 “half HD, CTP. The ability to transfer the image to an external computer via Wi-Fi or Ethernet

Multi-core processor built-in processors: NVIDIA® Jetson™ TX1 Quad-core ARM® Cortex®-A57 MPCore Processor NVIDIA Maxwell™ 1 TFLOPS GPU with 256 NVIDIA® CUDA® Cores

Wi-Fi interface, Ethernet, SD card

Built-in 256GB SSD hard drive

Windows 7, 8, 10 x 64 operating system

Minimum system requirements i5 or i7, RAM 32 GB

The use of a computer is necessary only for post-processing.

To sum up

The scanning process does not require a computer.

Average Artec Leo price is $29,800. If you wonder about artec leo where to buy, the best choice is online shop.

The best choice for fast, accurate and convenient scanning in any conditions and any objects, during which you watch the creation of a 3D model of the object directly on the built-in touch HD display:

• It does not require the application of markers, it is easy to start working with Artec Leo, as with an ordinary video camera: you point at the object and start shooting;
• Wide possibilities of synchronization with additional devices;
• Large diameter professional lens;
• Built-in 9-axis inertial system;

A powerful built-in processor and battery, together with a built-in SSD drive and the possibility of wireless connection of the Artec Leo portable scanner, make this model a really convenient professional 3D scanner of the new generation, created for the comfort of the user.
